Salt Spray Test Chamber-Type C (PP Material)
Economical Salt Spray Chamber Series-Type C
Function:
This multifunctional test equipment can be used for corrosion testing in simulated artificial environments and for comparative quality testing of metal materials with and without corrosion protection. It is suitable for rapid analysis of discontinuities, pores, and damage in organic and inorganic coatings. Furthermore, it can be used to compare specimens coated with the same coating for quality control purposes. Salt spray testing is particularly suitable for detecting discontinuities, such as pinholes and other defects, in certain metals, organic, anodic oxidation, and conversion coatings. It can also be used to accelerate corrosion during outdoor exposure by spraying sodium chloride salt spray into the gaps between sample surfaces. The following are some of the tests:
1. The neutral salt spray test (NSS) is applicable to metals and their alloys, metal coatings (anode and cathode), conversion coatings, anodic oxidation coatings, and organic coatings on metal materials.
2. The acetic acid salt spray test (AASS) is particularly suitable for testing decorative copper, nickel, and chromium, or nickel and chromium coatings; it has also been found to be suitable for testing anodic aluminum coatings.
3. The copper-accelerated acetic acid salt spray test (CASS) is applicable to testing decorative copper, nickel, and chromium, or nickel and chromium coatings; it has also been found to be suitable for testing decorative aluminum coatings. It is suitable for testing aluminum anodic coatings.
4. Intermittent Salt Spray Outdoor Accelerated Test (Scab Test): This is a similar test method developed primarily for the automotive industry to study sub-film corrosion, particularly on steel surfaces damaged by splashing sand and gravel. The scab test is applicable to various metal substrates with or without coatings. Some substrates will exhibit a scab-like appearance after testing; others will not.
Major Specifications:
| Product Name | Programmable salt spray testing machine |
| Product Model | CZ-1300C |
| Sample limit | This test equipment is prohibited from:
Testing or storing samples containing flammable, explosive, or volatile substances Testing or storing samples containing corrosive substances Testing or storing samples containing biological substances Testing or storing samples containing strong electromagnetic radiation sources Testing or storing samples containing radioactive substances Testing or storing samples containing highly toxic substances Testing or storing samples containing samples that may generate highly toxic substances during testing or storage |
| Nominal content | 663L excluding top sloping roof volume |
| Inner box size (mm) | 1300×600×850 W×H×D (excluding roof height)
Note: Top roof angle is 100°, roof height is 620mm |
| Outer box size (mm) | About 2180×1600×1100 W×H×D(mm) |
| Net weight of equipment | About 300 ㎏ |
| power supply | AC (220±10)V (50±0.5)Hz, single-phase, two-wire + protective ground. Ground resistance of the protective ground wire should be less than 4Ω.
TN-S or TT power supply requires the user to configure an air or power switch of appropriate capacity for the equipment at the installation site. This switch must be independent of the equipment. 5.2. Power Supply Capacity |
| Power capacity | Maximum power: 4.6KW Maximum current: 20A (recommended switch capacity is not less than: 30A, the switch is less than 2.5 meters away from the equipment power connection) |
Product Details
Test Standards:
1) GB/T2423.17-2008/IEC 60068-2-11-1981 Environmental testing for electrical and electronic products – Part 2: Test methods – Test Ka: Salt spray
2) ASTM.B117-2009 Standard test method for operating a salt spray tester
3) GB/T10125-2021 Artificial atmosphere corrosion testing – Salt spray test method (neutral salt spray test part)
4) GBT 20121-2006 / ISO11474-1998 Corrosion of metals and alloys – Corrosion tests in artificial atmospheres – Accelerated outdoor test in intermittent salt spray – scab test
